YN-ZXJ Series semi-auto carton box folder gluer machine
WHOLE MACHINE FEATURES
The Semi-auto carton box Folder gluer is the last process equipment for the carton box making, it is suitable to glue the 3 ply and 5 ply carton box. Machine with high efficiency, glue consumption is low, product cost is 10 times less than stitching. Produce carton beautiful and stable. Easy operation, save power and labor, running smoothly. It is a idea machine to make cartons
STRUCTURE AND FUNCTION OF THE MACHINE
1. Feed table
Photoelectric control the height of the feeding table, The feeding table can goes up and down automatically while the cardboard always stays at working place. reduce labor and improve work efficiency.
2. Glue part
Gluer wheel always keeps running even when the machines stops, which avoids glue drying and leaking
3. Press correction part
After gluing go into press correction part, adhesion smooth and firm.
Equipped automatic correction device to ensure the carton size is correctly
Equipped with blower Fan to dry the glue fast.
3. Horizontal Output
Automatic counter with sensor, when reaching to the set height, output cartons automatically. easy for bundling.
TECHNICAL PARAMETER
| Item | YN-ZXJ-2800 |
| Max size (L+W)*2 | 2800mm |
| Min size (L+W)*2 | 340mm |
| Max size(W+H)*2 | 1500mm |
| Min size (W+H)*2 | 260mm |
| Power | 2.2kw |
| Machine over size | 5300x2000x1800mm |
| Machine speed | 60pcs/min |
Note: Special requirement, Can be customized according to customer needs
